Masterflex L/S lufttryksdrev med variabel hastighed

Til brug på steder, hvor brug af elektricitet er upraktisk eller usikkert

• Flow-interval: 3,6 - 3.400 ml/min. Flow-intervallet afhænger af slangestørrelsen og drev o/min.
• Inkluderer regulator med 5-µm luftfilter og 1/4" NPT(F) forbindelse, automatisk smøring, 0 - 30 psi trykmåleinstrument og lyddæmper. Varier hastigheden ved at justere luftpresset med regulator.
• 3/4-hk lufttryks-motoren kræver meget lidt vedligeholdelse og genererer mindre varme end en elektrisk motor.
• Malet, vandsikkert  stålhus.
• God jordforbindelse til beskyttelse imod statisk elektricitet er afgørende for sikker drift.
• Reversible motor—purge tubing before or after pumping; pump fluid in either direction
• Brushless, maintenance-free motor offers ±0.1% speed control accuracy with a 6000 to 1 turndown ratio
• Powerful motors let you stack pump heads for increased flow rates and for multichannel applications
• Speed control input scalable 0 to 20 mA, 4 to 20 mA, or 0 to 10 V
• Pumping direction requires open collector or contact closure
• Start/stop/purge requires open collector or contact closure
• Tachometer output scalable 0 to 20 mA, 4 to 20 mA, 0 to 10 V, open collector
• Stackable, splash-resistant ABS plastic controller housing is IP33 rated; drive housing is epoxy finished steel, IP33 rated
• 6-ft (1.8-m) cable connects drive and controller
• Remote control capabilities via a DB25 female connector on back of controller
