Enheden er med indbygget kølespiral for tilslutning til ekstern køleenhed. F.eks. Julabo FL300. Tilslutning til køleenhed: Ø8 - 10 mm slangestuds Temperaturområdet er opgivet med et kølevandsflow ved 3°C.

Specifications
Shaking movement:
Orbit: orbital, 20mm
Max. shaker weight (with attachment): 20kg
Motor rating input / output:
Power consumption: 82 / 24W
Operating time: 1120W (at 230V), continuous
Speed range: 10 to 500rpm
Timer switch (select minutes/hours): 0 to 999 h/continuous
Heater power: 1000W
Temperature range: RT +5°C to 80°C
Temperature stability (200 ml H2O at target T = 37 °C, RT 25 °C): 0.1K
Dimensions (W x D x H): 580 x 750 x 525mm
Space required (W x D): 600 x 600mm
Weight: 55kg
Permissible ambient temperature: 15 to 32°C
Protection class acc. to DIN EN 60529: IP30
Interface: RS232
Supply requirements: 230V 50/60Hz
Tested to DIN EN IEC 61010-1.
