Reproducibility - pumping and dosing

• Flow rates of 0.38 - 813 ml/min with single-channel pump heads
• Multi-channel flow rates from 0.005 - 364 ml/min
• This pump drive is suitable for multi-channel operation
• Low speed range from 5 - 120 rpm
• Control speed (rpm), direction and On/Off function via analog interface for 0 – 10 V or 4 – 20 mA or digital RS 232 interface
• Flow characteristic of pump heads in combination with various tubing diameters is pre-programmed for accurate flow rate numbers
• Digital read-out of:
  - Speed (rpm)
  - Tubing diameter
  - Flow rate in ml/min
  - Dosing volume
  - Interval dosing
  - Pause function
• Easily change all process parameters via control buttons
• These models connect to an optional foot-pedal remote control via cable to start and stop your pump drive outside a closed fume hood increasing your personal safety and superior ease of use in multiple sample fills
• These models feature electronic speed control at an accuracy of ± 0.5 %
• A press of the max button accelerates the filling and draining of your tube
• At the press of a button the pump operates clockwise or counter-clockwise
• Calibrate your flow volume and flow rate individually

The pumphead is not included. Please order separately.
